Van Cổng ETM

Giá: Liên hệ

Giao hàng miễn phí trong 4h (Nếu đặt hàng sau 17h Cao Phong sẽ giao hàng vào hôm sau). Tìm hiểu thêm

Liên hệ với chúng tôi để có giá tốt nhất
Gọi mua:0906.818.600

Sơ lược về sản phẩm

  • Giao hàng miễn phí trong 3 tiếng (giao hàng từ 7h đến 21h hàng ngày)
  • Đổi sản phẩm lỗi miễn phí trong 15 ngày .
  • Bảo hành chính hãng 12 tháng

Gate Valves (F4 Type)

DIN Standard F4 Gate valves / (Length acc.to DIN EN 558-1,face to face series 14 )
DIN F4 Gate valve
DIN absperrschieber F4
DIN Válvulas de compuerta
DIN F4 šoupátko stavební délka dle DIN EN558-1 serie 14
DIN Standard F4 sluseventil (lengde iht. DIN EN 558-1, bygge lengde serie 14)
DIN Standardında F4 Sürgülü Vana
Van cổng chuẩn DIN kiểu F4

ETM Code No. : ETM FIG.F.160
This type ETM gate valve can be used in Industry, Powerstations, Flue gas purification plant, processing technology, gas supply,

vapor facilities, thermal oil applications, recycling facilities, vacuum facilities, ammonia, hot water, heating technology, district

heating, cooling and freezing systems, general plant manufacturing, steam systems.

All ETM valves – is classed leak rate “A” in accordance with EN 12266-1.

Products:
ETM-FIGURE F-BS/EN Standard F4 gate valve PN 10 Bar with Flanges According to DIN EN 1092-1
ETM-FIGURE F-BS/EN Standard F4 gate valve PN 16 Bar with Flanges According to DIN EN 1092-1

Material Equivalence:
EN Material Name EN Number Forgings ASTM Material Forgings
EN Material Name———————–EN Number ————Forgings—————–ASTM Material——————-Forgings
EN 10213 GP240GH———————1.0619——————1.0460—————–ASTM A216 WCB—————–A105
EN 10213 G20Mo5———————–1.6220——————1.0437—————–ASTM A352 LCB——————A352 LF2
EN 10213 G17CrMo5-5——————1.7357——————1.7335—————–ASTM A217 WC6—————–A182 F11
EN 10213 G17CrMo9-10—————-1.7379——————1.7380 —————-ASTM A217 WC9—————–A182 F22
EN 10213 GX5CrNi19-10—————-1.4308——————1.4301—————–ASTM A351 CF8—————–A182 F304
EN 10213 GX5CrNi19-11-2————-1.4408 —————–1.4401—————–ASTM A351 CF8M—————-A182 F316

Features:
Cast steel PN10 ,PN16, DN40 to DN1000
Length acc.to DIN EN 558-1,face to face series 14 (DIN3202 series F4)
Rising, non rotating stem
Non rising stem
Welded seat in stellite or Cr-steel
Solid stem make of stainless material
Full port design Full length wedge guides
Stem sealing in graphite Raised, turning stem
Back sealed stem Welded seat in stellite or Cr-steel
High-tensile Gland Packing Self adjusted gland
Top Flange to ISO 5210
Gear operated
Electric actuator
Position indicator
Locking / interlock
Stem protection
Stem extension
Drain plug
By pass

Mediums:
Standard: Steam, gases, hot water, thermal fluids, hot oil, process water, etc.
Stainless Steel: Process water, aggressive media, etc.

Requirements and testing:
The test are carried out according to DIN EN12266-1
Shell test : nominal pressure (PN)X1.5
Tightness of seat :nominal pressure (PN)X1.1
Certificate of conformity in according to with PN-EN10204
Design according to PN-EN12516-2
Valves have been submitted for appraisal of conformity according to the directive pressure equipment directive 97/23/EC.

Installation:
They can be installed on pipelines in a vertical or horizontal and operation only when fully open or closed

Connection:
Flanged according to EN1092-1 or to customer request
Face to face dimensions according to EN558-1 14 Series (DIN3202 Series F4)

Operation:
Handwheel (If required)
Electric actuator
Gear box
Flange ISO5210 (Ready for actuator)
